PRODUCT CENTER

S1625

1.Imported felt, wear resistance, high breathability, ensure high flatness of the cutting platform.
2.Advanced rolling platform, size can be customized, auto feeding, cutting, punching, creasing, and etc., easy to operate.
WhatsApp: +86 13153108238
E-mail: sales@sanqiangcnc.com
Get a Quote

Product Details

Main Features

1.Imported felt, wear resistance, high breathability, ensure high flatness of the cutting platform.

2.Advanced rolling platform, size can be customized, auto feeding, cutting, punching, creasing, and etc., easy to operate.

Applicable Materials

Photo paper, car sticker, KT board, self-adhesive film, carbon fiber, glass fiber, fiber cotton, prepreg, aramid fiber, ceramic fiber, cloth, coil mat, leather, felt, carpet, sound-absorbing cotton, silicone rubber, and other non-metallic flexible materials.

Parameters

Model

S1625

XYZ Working Area (mm)

1600*2500*50

Control System

Intelligent Cutting Machine control system

Max. Cutting Speed

120m/min

Drive Mode

Servo Motor

Cutting Tools

Oscillating Knife + Drag Knife (Kiss-cut Tool/V-cut Tool/Creasing Tool/Milling Tool optional)

Repeatability

0.02mm

Transmission Mode

Taiwan Rack Drive

Guide Rail

Taiwan Hiwin Linear Guide Rail

Working Table

Automatic Feeding Platform

Working Voltage

AC220V±10% / AC380V±10%, 50Hz

Warranty

1 Year

Machine Dimension (mm)

3600*2500*1350

Packing Dimension (mm)

3600*2600*1550

Gross weight

1200kg
